SKU: SMS-868-V167-5200000N43
Price
BBB Accredited Business: A+ | Secure Checkout
Estimated to ship in 4 to 8 weeks. Call 866-285-8646 or email [email protected] for current lead time.
*Add to cart to view available shipping options and costs.
Questions? We're here to help. Call 866-285-8646 or email us.
| Tank Capacity | 4,400 gallons |
|---|---|
| Tank Style | Cone Bottom Tank |
| Tank Dimensions | 90'' Dia x 200'' H |
| Warranty | Manufacturer's Limited 3-Year Warranty |
| Liquid Access | 1 Manway / Lid |
| Weight / Ship Class | 1400 lbs. / Ship Class 300 |
| Outlet / Drain 1 | Outlet Fitting By Request (additional charge will apply) |
| UV Stabilized | Yes |
| Translucent | Yes |
| Environment | Above Ground |
| Gallon Indicators | Yes |
| Specific Gravity | 1.5 |
The 5,500 Gallon Cone Bottom Tank, 90'' Diameter x 241'' High provides 5,500 gallons of liquid storage capacity in a cone-bottom tank configuration for mixing, batching, draining, and liquid handling...
The 2,500 Gallon Cone Bottom Tank, 90'' Diameter x 125'' High provides 2,500 gallons of liquid storage capacity in a cone-bottom tank configuration for mixing, batching, draining, and liquid handling...
The 4,100 Gallon Cone Bottom Tank, 90'' Diameter x 197'' High provides 4,100 gallons of liquid storage capacity in a cone-bottom tank configuration for mixing, batching, draining, and liquid handling...
The 3,000 Gallon Cone Bottom Tank, 90'' Diameter x 144'' High provides 3,000 gallons of liquid storage capacity in a cone-bottom tank configuration for mixing, batching, draining, and liquid handling...
The 6,500 Gallon Cone Bottom Tank, 90'' Diameter x 273'' High provides 6,500 gallons of liquid storage capacity in a cone-bottom tank configuration for mixing, batching, draining, and liquid handling...
Cone bottom tanks are used when drainage, settling, mixing, cleanout, or controlled discharge is important for the liquid handling process. For this model, review capacity: 4,400 gallons, dimensions: 90'' Dia x 200'' H, access: 1 Manway / Lid, outlet/drain: Outlet Fitting By Request (additional charge will apply).
Confirm cone angle, stand or support requirements, outlet location, overall height, access opening, and how the tank will be drained or cleaned. Before order release, confirm current lead-time note: Estimated to ship in 4 to 8 weeks. Call 866-285-8646 or email [email protected] for current lead time.; listed shipping data: 1400 lbs. / Ship Class 300.
Compare gallons, footprint, height, clearance, and installation space before choosing the final model.
Check liquid access, outlet or drain details, manway or lid information, and documentation before ordering.
Confirm lead time, destination access, unloading needs, and any freight requirements for the project.
| Tank Capacity | 4,400 gallons |
|---|---|
| Tank Style | Cone Bottom Tank |
| Tank Dimensions | 90'' Dia x 200'' H |
| Liquid Access | 1 Manway / Lid |
| Outlet / Drain | Outlet Fitting By Request (additional charge will apply) |
| Specific Gravity | 1.5 |
| Weight / Ship Class | 1400 lbs. / Ship Class 300 |
Cone bottom tanks help move liquid or material toward the discharge point for draining, settling, mixing, or cleanout workflows.
Many cone bottom applications require a compatible stand or support arrangement. Review the product documentation and installation requirements.
Confirm the tank height with support, outlet size/location, access opening, liquid compatibility, and site clearance.
Send us the SKU SMS-868-V167-5200000N43 and your application details. We can help compare tank style, capacity, fittings, documentation, and lead-time questions.
