Please configure your product to view product specifications.
- Documentation: Specifications [] https://products.storemorestore.com/hubfs/StoreMoreStore/Kardex-Lektriever-Megamat-Vertical-Carousel/Kardex-Lektriever-Megamat-120-1411S-SpecSheet.pdf
- Revit: https://fetchbim.com/product/641/ssg-carousel-vertical-file-pcs
- Documentation: Technical Drawing [] https://products.storemorestore.com/hubfs/StoreMoreStore/Kardex-Lektriever-Megamat-Vertical-Carousel/Kardex-Lektriever-Megamat-120-1411S-Technical-Drawing.pdf
- Product Width: 100.79''
- Product Depth: 57.37''
- Product Height: 98.43''
- Material: Steel
- Core Material: Galvanized or ESD Galvanized Steel
- Storage Type: Vertical Carousel Filing System
- File Storage Format: Letter/Legal
- Unit Style: Wide Short
- Carrier Type: Multipurpose Carrier
- Number of Carriers: 14
- Total Storage Levels: 14
- Intermediate Shelves: No
- Total Linear Filing Inches: 1204
- Shelf Depth: 16.1''
- Carrier Clear Height: 9.84''
- Carrier Clear Width: 86.62''
- Carrier Clear Depth: 16.14''
- Max Capacity Per Carrier: 330 lbs.
- Max Capacity Per Level: 330 lbs.
- Work Counter Type and Height: Standing 39.4 in. 1000mm
- Door Type: Standard Manual Bi-parting Door w/Keylock
- Access Opening clear Height: 19.41 in. 493mm
- Access Lighting: Full Width Light Above Access Opening
- Power Supply: 110 Volt /1-/60 Hz
- Control: T0 Control
- Controller Location: Work Counter/Table
- Safety Features: Safety light curtain, emergency stops left and right, upper and lower mechanical safety bars, imbalance detection, emergency service switch, access panel safety switches, manual hand crank
- Finish: Light Gray/Blue
- Cycle Speed: 7.0 inches / second
- Average Access Time: 5.5 seconds
- Noise Level: < 60 db(A)
- Computer Interface: No
